New Kubota U17-3a VHG F1 Mini Excavator
Unmatched Compact Versatility & Zero Tail Swing. The Kubota 1.7-tonne mini excavator is the ultimate choice for tough jobs in ultra-confined spaces. Featuring a hydraulic Variable Track Gauge (VHG), the undercarriage retracts down to just 990mm to clear narrow garden gates or doorways, and expands out to 1,240mm for absolute stability when digging. Boasting a true zero tail swing design, the chassis rotates smoothly within the width of its tracks, eliminating rear impact risks against walls or fences. Equipped with single-line auxiliary hydraulics to run breakers and attachments efficiently, alongside a robust canopy frame (F1/ROPS), this plant staple delivers heavy-duty excavation performance with nimble, precise control.
Ultra-Compact Design
- Variable Track Gauge: Hydraulically scales from 990mm to 1,240mm in seconds.
- Zero Tail Swing: Rear counterweight stays within track footprint for tight spaces.
- Folding Dozer Blade: Quick-fold extension pins allow easy track-width matching.
- Protected Hoses: Boom and bucket hydraulic cylinders are routed safely to avoid site damage.
Commercial Procurement
- Kubota Anti-Theft: Fitted with the industry-renowned electronic coded key system.
- Local Support: Complete handover, maintenance, and warranty from Stubbings Bros.
- Attachments: Full line of buckets, quick-hitches, and augers available in stock.
Performance Power
- Kubota E-TVCS Engine: Renowned 3-cylinder diesel delivers maximum torque and low vibration.
- Auxiliary Hydraulics: Single-line piping ready to power breakers, augers, and compactors.
- Powerful Forces: Exceptional bucket breakout force handles heavy clay and root systems easily.
- Dual-Speed Travel: Switchable tracking speeds for faster repositioning across open sites.
Safety & Control
- F1 ROPS/TOPS Canopy: High-visibility open workspace meeting all legal safety standards.
- Pilot Controls: Ergonomic wrist-rest joysticks provide smooth, fatigue-free hydraulic operation.
- Engine Start Safety: Hydraulic lockout lever prevents accidental movement on start-up.
- Isle of Wight Delivery: Fully prepped, fueled, and tested by our on-site workshop team.
Technical Specifications – Kubota U17-3a VHG
| SPECIFICATION | DETAILS |
|---|---|
| Operating Weight | 1,650 kg |
| Engine Model | Kubota D902-E3 (Stage V Compliant) |
| Engine Output | 11.8 kW / 16.0 HP @ 2300 rpm |
| Track Width Range | 990 mm to 1,240 mm (Hydraulic Adjust) |
| Max. Digging Depth | 2,310 mm |
| Max. Digging Reach | 3,840 mm |
| Auxiliary Hydraulic Flow | 27.7 L/min (Single Line) |
| Tail Swing Type | Zero Tail Swing |
Model Variations & Product Codes
| Model Code | Configuration / Specification | Product Code |
|---|---|---|
| U17-5 VHG F1 | Canopy, Rubber Tracks, Foot Auxiliary, Variable Undercarriage | RA26310580 |
| U17-5 VHG S1 | Canopy, Rubber Tracks, Hand Auxiliary 1, Variable Undercarriage | RA26320580 |
| U17-5 VHG S2 | Canopy, Rubber Tracks, Hand Auxiliary 1&2, Variable Undercarriage | LR10900110 |
Authorized Kubota Construction Dealer
Stubbings Bros: Unrivaled compact plant support and genuine parts on the Isle of Wight.
