New Kubota KX018-4 VHG Canopy Mini Excavator
Superior Reach, Retractable Agility: The Ultimate Ground-Working Specialist with Variable Undercarriage. Raising the bar for compact digger performance, the Kubota KX018-4 VHG balances incredible stability with class-leading working power. Equipped with a hydraulic Variable Undercarriage, the track width smoothly telescopes from a slimline 990 mm for passing through restricted gates and side passages, up to an expanded 1,300 mm footprint to maximize lifting power over the side. This premium VHG layout features a structural 4-Post Safety Canopy, providing operators with an open, unrestricted 360-degree field of vision and zero-obstruction access on fast-moving civil, utility, or landscaping sites. Riding on heavy-duty Rubber Tracks to eliminate surface scarring, and boasting an efficient Standard Arm system that creates maximum breakout force and lightning-fast cycles, the KX018-4 VHG delivers premium utility performance whenever space is short.
Variable Undercarriage
- Hydraulic Expansion: Shift seamlessly between a tight 990mm transport width and an expanded 1,300mm operational footprint.
- Confined Site Transit: Seamlessly maneuvers down narrow garden lanes, property boundaries, and internal site gaps.
- Optimized Footprint: Fully extending the tracks dramatically increases digging leverage and lifting stability over the side.
360° Safety Canopy
- Panoramic Blindspot Vision: Complete open frame styling guarantees flawless sightlines to the machine corners and bucket teeth.
- ROPS/FOPS Safety Kit: Heavy-gauge overhead structure provides fully certified protection against vehicle rollover and falling rubble.
- Rapid Access Step-In: Eliminates opening cab glass and doors, allowing teams to move seamlessly from ground work to control joystick.
High-Grip Rubber Tracks
- Delicate Surface Defense: Durable rubber compound distributes machine weight evenly to guard lawns, paths, and brickwork.
- Expandable Dozer Blade: Dual side-hinged blade wings flip back or anchor outward manually to perfectly mirror track alterations.
- Protected Hydraulic Lines: Critical boom lines are routed overhead and inside the iron framework to safely eliminate snagging risks.
Efficient Standard Arm
- High Breakout Strengths: Main arm geometry is carefully counterbalanced to supply vast bucket digging and crowd pressures.
- Auxiliary Hydraulic Piping: Comes standard with auxiliary single-line services plumbed to the arm end for hydraulic breakers.
- Anti-Theft Coded Key: Protected by Kubota’s high-grade factory engine immobilizer keys for absolute peace of mind.
Technical Specifications – Kubota KX018-4 VHG (Variable Track Canopy)
| SPECIFICATION | DETAILS |
|---|---|
| Operating Weight | 1,720 kg |
| Engine Model | Kubota D902 (Stage V Liquid-Cooled Diesel Engine) |
| Engine Output | 11.8 kW / 16.0 PS @ 2300 rpm |
| Operator Station | Open 4-Post Canopy (ROPS / FOPS Certified) |
| Track Configuration | High-Performance Premium Rubber Tracks |
| Undercarriage Type | Hydraulic Variable Tracking System (990 mm to 1,300 mm) |
| Arm Configuration | Standard Efficiency Arm Assembly |
| Auxiliary Hydraulic Lines | Single-Line Auxiliary Piping to Arm End |
| Max. Digging Depth | 2,380 mm |
| Max. Digging Reach | 3,920 mm |
| Max. Dumping Height | 2,380 mm |
| Bucket Breakout Force | 15.9 kN (1,620 kgf) |
| Fuel Tank Capacity | 21 Litres |
| Anti-Theft System | Kubota Thatcham-Approved Coded Key Immobilizer |
Model Variations & Product Codes
| Model Code | Configuration / Specification | Product Code |
|---|---|---|
| KX018-4 VHG | Canopy, Rubber Tracks, Variable Undercarriage, Standard Arm | RGF2613150 |
| KX018-4 VG | Cabin, Rubber Tracks, Variable Undercarriage, Standard Arm | RGF2623150 |
