MODEL FEATURES

Continuous 360° rotation;

ROTO 50.26 S-PLUS can lift 5000kg, for a maximum lift of 25.9 m.

The ROTO S PLUS models with 125kW/170HP engine, are combined with the Eco Power Drive (EPD) electronic management that automatically controls and adjusts the engine revolutions based on operating conditions. This technology achieves a reduction in fuel consumption of up to 18%.

Multi-position stabilisers with automatic self-levelling and self-stabilisation;

Tilting cab: the exclusive Merlo cab ensures greater levels of comfort, ergonomics and safety. From the driver’s seat the operator can activate the cab’s tilting via the dedicated button. The longitudinal inclination reaches 20°, allowing you to monitor the movements of the load when working at a height;

Intelligent hydropneumatic suspensions on axles, giving great frame levelling control (12% lateral and 4% front inclination) and the possibility to the machine when is on wheels of varying the height according to the soil;

Exclusive MCDC (Merlo Dynamic Load Control): the system allows you to collect different parameters submitted by the machine, analyse them in real time and create a load diagram that allows the operator, through the new LCD display, to understand the perimeter within he/she can operate in maximum safety;

Double hydraulic Load Sensing and Flow Sharing pumps which provide greater system efficiency, simultaneous movements, more precision movements, lower consumption and less overheating of components and oil.

S-PLUS models come as standard with Grammer Warmed Seat, Roof Wiper, Sunshade, LED light on cab, Lights on boom, Towing Hook and Prearrangement for platform.

Engine: FPT 4.5 125Kw/170 Hp Stage IV
Transmission: Hydrostatic
Hydraulic system: 2 x Load Sensing + Load Sharing, 138+100 l/m – 250/230 Bar
Electronic Joystick
Cab: premium

• Multiposition stabilisers
• Lift capacity 5000kg
• Lift height 25.9 meters
• Tilting cab
• Automatic self-levelling on stabilisers & self-stabilisation
• Dynamic Load Control + Double hydraulic pumps

View Merlo P50.26 Brochure

---

ATTACHMENTS

The widest range of attachments on the market, designed and developed by Merlo. This ensures the reliability and maximises the performance and comfort of the telehandlers produced by Merlo. The purpose is to make your work easier and more productive, with advanced technical solutions and a never ending research. For this Merlo is also able to produce special attachments for the most demanding customers. To make the most of Merlo telehandlers in every field, various ranges of equipment dedicated to different applications, we have selected the top most preferred attachments.

Please download their latest attachment brochure below to see the full range.
