MERLO 33.9-75G

MODEL FEATURES

This  model is well known for compact dimension and impressive performance, giving a  load placement height of 8.6 meters and 3.3 tonne as maximum capacity.

Hydrostatic transmission, which makes the workphases simpler and more precise. Moreover, the dry disc brakes limit the absorption of energy, thereby reducing the machine’s fuel consumption.

The 55.4kW/75hp Deutz engine without the need for AdBlue combines with the 40km/h hydrostatic transmission to provide power on demand for all site conditions.

The hydraulic gear pump provides  optimal simultaneous control of all movements. The new cab, of generous dimension, is mounted on Silent Block, winch drastically reduce vibrations, guaranteeing maximum comfort and maximum visibility for the operator.

This model comes with standard Electrohydraulic Joystick, Inching Control, Roof Viper, Reversible Fan, Rear Diff Lock, Automatic  Parking Brake or the Tac-lock, system for hydraulic  clamping of the attachments which further improves operating comfort.

Engine: Deutz 2.9 Tier 4 final 55.4KW /75HP
Transmission: Hydrostatic
Maximum speed: 40km/h
Hydraulic system: Gear 98L /min 210 bar
Hydraulic valve block: open centre
Overload system: Auto Block

• Lift Capacity 3300kg
• Lift height; 8.6 meters
• Electrohydraulic joystick
• Hydrostatic transmission
• Gear hydraulic pump

View TF33.9 Brochure

---

ATTACHMENTS

The widest range of attachments on the market, designed and developed by Merlo. This ensures the reliability and maximises the performance and comfort of the telehandlers produced by Merlo. The purpose is to make your work easier and more productive, with advanced technical solutions and a never ending research. For this Merlo is also able to produce special attachments for the most demanding customers. To make the most of Merlo telehandlers in every field, various ranges of equipment dedicated to different applications, we have selected the top most preferred attachments.

Please download their latest attachment brochure below to see the full range.

View Construction Attachment Brochure  View Agricultural Attachment Brochure
