MERLO TF50.8T-170

MODEL FEATURES

The Eco Power Drive (EPD) and hydrostatic transmission automatically control and adjust the engine revolutions based on operating conditions. As a result, the engine speed is disconnected from the accelerator pedal. This technology achieves a reduction in fuel consumption of 18%. On this model the EPD TOP system is as standard and offers automatic RPM speed control in relation to joystick movements in order to increase hydraulic performance on demand.

T range comes with standard Chassis Levelling: the tilt correction system integrated into the chassis, allows the operator to correct the lateral inclination by 8%; this permits the telescopic boom to be moved out perpendicularly to work in condition of maximum safety.

The standard cab gives easy access, astounding space with great visibility: generous in dimensions, the cab is mounted on Silent Block, which drastically reduce vibrations, guaranteeing maximum comfort and visibility, whist the option of cab suspension provides a superior ride unique to Merlo.

Heavy Duty versions are equipped as standard with full MCDC (Merlo Dynamic Load Control) coupled with a large 10.1” colour display and attachment recognition, showing machine’s geometric configuration, boom extension, angle and handled load.

This model come standard with Pick up Hitch, Trailer Braking and Tractor Type Approval for your towing requirements.

Engine: FPT 4.5 125kW/ 170hp
Transmission: Hydrostatic
Hydraulic system: Load Sensing + Flow Sharing 150 l/m 210 Bar
Electronic Joystick

Maximum capacity 5000kg
Lift Height 7.8 meters
Frame leveling
Optional Cab Sunspension
Optional CV Tronic
