MERLO TF45.11 T-170 TELEHANDLER

Out of Stock

Contact us for a price


MERLO TF45.11 T-170



The Turbofarmer 45.11 has been designed to work in the most demanding conditions where performance in terms of lifting capacity and engine power make all the difference.

Part of the HEAVY DUTY range, this TF can lift 4.5 tonnes with a maximum lift height of 10.5 meters: this new concept can be customised according to operational needs and thanks an efficient 4.5L FPT engine it develops 170 hp (125kW), offering a maximum speed of 40 km/h.



MODEL FEATURES

The Eco Power Drive (EPD) and hydrostatic transmission automatically control and adjust the engine revolutions based on operating conditions. As a result, the engine speed is disconnected from the accelerator pedal. This technology achieves a reduction in fuel consumption of 18%.

On this model the EPD TOP system is as standard and offers automatic RPM speed control in relation to joystick movements in order to increase hydraulic performance on demand.

T range comes with standard Chassis Levelling: the tilt correction system integrated into the chassis, allows the operator to correct the lateral inclination by 8%; this permits the telescopic boom to be moved out perpendicularly to work in condition of maximum safety.

The standard cab gives easy access, astounding space with great visibility: generous in dimensions, the cab is mounted on Silent Block, which drastically reduce vibrations, guaranteeing maximum comfort and visibility, whist the option of cab suspension provides a superior ride unique to Merlo.

Heavy Duty versions are equipped as standard with full MCDC (Merlo Dynamic Load Control) coupled with a large 10.1” colour display and attachment recognition, showing machine’s geometric configuration, boom extension, angle and handled load.

This model come standard with Pick up Hitch, Trailer Braking and Tractor Type Approval for your towing requirements.

Engine: FPT 4.5 125kW/ 170hp
Transmission: Hydrostatic
Hydraulic system: Load Sensing + Flow Sharing 150 l/m 210 Bar
Electronic Joystick
  • Lift Capacity 4500kg
  • Lift Height 10.6 metres
  • Frame levelling
  • Optional CVTronic
  • Optional Cab Suspension


View Merlo TF45.11 Brochure




ATTACHMENTS

The widest range of attachments on the market, designed and developed by Merlo. This ensures the reliability and maximises the performance and comfort of the telehandlers produced by Merlo. The purpose is to make your work easier and more productive, with advanced technical solutions and a never ending research. For this Merlo is also able to produce special attachments for the most demanding customers. To make the most of Merlo telehandlers in every field, various ranges of equipment dedicated to different applications, we have selected the top most preferred attachments.

Please download their latest attachment brochure below to see the full range.


View Construction Attachment Brochure  View Agricultural Attachment Brochure






SKU:.NTF45.11 T-170
...
