MERLO MF40.9 CS

MODEL FEATURES

The Multifarmers are equipped with mechanical Power Take Off as standard that, in combination with the 3 point rear linkage and rear spool valves, allows mounted and trailed attachments to be connected.

The MF40.9 has a lift capacity of 4 tonnes lifted up to 8.8 meters. This range is equipped with 4.5l Deutz engine which develops 170hp/125kW, coupled with hydrostatic transmission and Eco Power Drive (EPD) that automatically control and adjust the engine revolutions based on operating conditions. As a result, the engine speed is disconnected from the accelerator pedal. This technology achieves a reduction in fuel consumption of 18%.

The EPD TOP system on this model offers the following models: Heavy Loads, Eco and Speed Control. “Eco” mode optimises performance during light operations, reducing consumption; “Speed Control” mode allows you to set and maintain the driving speed in relation to joystick movements in order to increase hydraulic performance on demand; “Heavy Load” function, on the other hand, allows the machine’s full potential to be exploited in the most demanding contexts, delivering more power to the machine.

This model is equipped as standard with Continuously Variable Transmission (CVTronic) which ensures a smooth and progressive acceleration 0-40km/h, without interruption for a gear change: this provides higher starting torque at low speeds, lower consumption and greater efficiency at high speeds.

The CS model comes with standard Cab Suspension: the exclusive patented and dampened CS with active hydropneumatic suspension, can be switched off directly by the operator. The low frequency system allows the drastic reduction of vibrations inside the passenger compartment and facilitates the absorption of the stress and vibrations transmitted during the transfer and work phases, even on rough grounds. Merlo is the only one on the market providing such an innovative and effective feature.

This model is equipped with the exclusive new generation full MCDC (Merlo Dynamic Load Control) coupled with a large 10.1” colour display and attachment recognition, showing machine’s geometric configuration, boom extension, angle and handled load.

The whole range can counts on the standard Tilt Correction System that, integrated into the chassis, allows the operator to offset the ground slopes to work in total safety. On sloping terrain the machine can correct the lateral inclination by 8%, permitting the boom to be moved out perpendicularly to work in conditions of maximum efficiency and safety.

This model comes standard with Pick up Hitch, Trailer Braking and Tractor Type Approval for your towing requirements.

Engine: Deutz 4.5 125kW/ 170hp
Transmission: Hydrostatic CVTronic
Hydraulic system: Load Sensing + Flow Sharing 150 l/m 210 Bar
Electronic Joystick

• Lift Capacity 4000kg
• Lift height 9 metres
• 2 speed PTO
• Cab Suspension
• Frame Levelling Control
• CVTronic

View Merlo MF40.9 Brochure

---

ATTACHMENTS

The widest range of attachments on the market, designed and developed by Merlo. This ensures the reliability and maximises the performance and comfort of the telehandlers produced by Merlo. The purpose is to make your work easier and more productive, with advanced technical solutions and a never ending research. For this Merlo is also able to produce special attachments for the most demanding customers. To make the most of Merlo telehandlers in every field, various ranges of equipment dedicated to different applications, we have selected the top most preferred attachments.

Please download their latest attachment brochure below to see the full range.

View Construction Attachment Brochure  View Agricultural Attachment Brochure
